Mortar M224 Clevis Leg 11579016

Mortar M224 Clevis Leg 11579016 View larger

C01-9

New

Mortar M224 Clevis Leg

PN 11579016

NSN 5340-01-176-8767

More details

25,00 €

NameValue
SHANK LENGTH1.000 INCHES NOMINAL
OVERALL WIDTH1.641 INCHES NOMINAL
END RADIUS0.570 INCHES NOMINAL
FORK SPAN WIDTH1.251 INCHES NOMINAL
DISTANCE FROM PIVOT PINHOLE CENTER TO ROD CONNECTION END1.250 INCHES NOMINAL
FORK ARM THICKNESS0.195 NOMINAL INCHES
STYLE DESIGNATORCLEVIS
SPECIAL FEATURESSTEEL ALLOY 4130 OR 8620,ASTM- A322 OR ASTM-A331; PHOSPHATE COAT, TYPE M OR Z, CLASS 2, SPEC D0D-P-16232; 2.12 IN LG; 0.75 IN W; 2 HOLES 0.188DIA;2 ARMS 0.69 IN LG AND 0.43 IN APART, EACH ARM 0.16 IN W; ROUNDED EDGES
